Titan LED Engine, 15W, CRMX + Wired DMX
Say hello to our next-generation multi-purpose light. In addition to being a battery-powered uplight and spotlight with 5 different beam options, multiple PixelBricks can be connected to form clusters and shapes. With about 10cm edge length and 1kg weight, it is small and lightweight while still featuring a powerful output of high-quality light which meets the highest demands of film, TV and stage clients.



[layerslider id="27"]

技术参数

光学
Order Code: PB15
LED Engine: Titan LED Engine
Colors: RGB Mint Amber
Total LED Power: 15W
Power Draw: 12W
Light output: 2700K, 3200K, 5500K:* 388lm, 450lm, 375lm
CRI(Ra)/TLCI 3200-6500K*: ≥96
Beam Angle: 13°
Strobe: 0 – 25Hz
Pixels: 1
*Typical value

供电
Battery Lifetime: 70 % after 300 cycles
Battery Runtime: up to 20 hours
Charging Time (nominal): 4 hrs
Input Voltage: 24VDC
Input Current: 0.8A
控制
Wired DMX: Yes (via PWB-2-86)
CRMX Receiver: Built-in
Wireless Frequencies: CRMX 2.4GHz, UHF,
Bluetoothl
Range (m/yds): 300 / 330yds

结构
Housing: Aluminium
IP Rating: IP65
Ambient Temperature (°C/°F): 0°- 40° / 32°- 104°
Weight (kg/lbs): 1.12 kg / 2.47 lbs
Dimensions (mm/inches): 91 x 91 x 94 / 3.6 x 3.6 x 3.7
控制设备

Astera ARC1

AsteraBox

CRMX Nova TX




Astera 系统

智能(双向)控制系统,红外遥控、无线DMX和应用程序协同工作,可以快速方便地设置、监控和调整,从而实现大型活动无线照明控制。
App控制(UHF)

Create complex programs out of colors, effects, and settings. PixelBrick will remember and repeat these effects without requiring a constant wireless link.
Quickly create groups of lights, assign positions and select which Tube should receive commands.

Monitor

Keep a complete overview of the status and all settings of your PixelBrick while you operate them.
View battery status, radio signal, DMX address and which lights you have targeted.
Diagnose individual PB15 PixelBrick and even get informed if a light is being moved or switched off.
This works while you control lights by the app but also if PB15 PixelBrick is controlled via DMX.

Set Up Faster

Set up your Film Light conveniently out of the distance.
Set DMX address and DMX footprint for one or several PB15 PixelBrick; 50 units can be prepared in less than 5 minutes out of the distance.
After your job, do a quick master reset of all settings or a partial one of only selected settings.

无线DMX (2.4GHz)

LumenRadio

The AsteraBox works as a wireless DMX transmitter; just connect it with the included XLR adapter to your DMX console and you can transmit 1 DMX universe with CRMX technology, the most stable wireless DMX protocol available.

Compatibility

We included the most reliable wireless DMX module on the market compatible with CRMX and other wireless DMX standards but not W-DMX G5 and City Theatrical.

红外遥控

Simple commands like ON/OFF, colors, preloaded effects etc can be sent with our infrared remote control directly to the lights.
When programming lights with the AsteraApp the IR remote can be used for confirming settings on individual lights.



独特性能
